3D-printed replacement bed extender rack pin sleeve made for the 2001-2010 Ford Explorer Sport Trac: a simple way to replace a cracked, lost or hard-to-find original part.
About this part
My pin lock cracked and I was able to retrieve the parts so I could reproduce them.
This design is made in three parts, two shells and a nut.
On the shells the inside wings are meant to be fit together and slide into the key (the red plastic part from the original peace’s), the pin (metal part from the original peace’s) should fit snugly against the notch inside the barrel produced by sandwiching the two shells together,
it may be necessary to sand down the notch slightly so you can still pull the pin outward once assembled,
this design seemed a more stable option then the original locking pin design.
Compatible vehicles
- 2001-2010 Ford Explorer Sport Trac
Always compare with your original part before ordering. Fitment can vary by trim level and production date.
Specifications
| Part | Bed Extender Rack Pin Sleeve |
|---|---|
| Make | Ford |
| Model | Explorer Sport Trac |
| Year | 2001 |
| Production | 3D printed to order (FDM) |
| Design files | 3 (STL) |
| Part number | CAT-a3d50b90 |
Print settings
Standard FDM printing settings:
- Layer height: 0.2mm
- Infill: 70%
- Supports: As needed
How to order
This part is in our catalogue and is printed on request. Send us a request with your vehicle details and we will reply with a price and delivery time.
More Ford parts
Browse all Ford replacement parts or search the full 3D-printed car parts catalogue.
Design credit: original design on Thingiverse, licensed CC BY-SA-4.0.
