Under Hood Light Cover – 1997-2004 Chevrolet Corvette C5
Under Hood Light Cover – 1997-2004 Chevrolet Corvette C5
Need a replacement under hood light cover for your 1997-2004 Chevrolet Corvette C5? This 3D-printed part is made to order to replace a broken, worn or missing original piece.
About this part
This is a replacement lens for the 1997 - 2004 C5 Corvette under hood light.
It is not an exact replacement, but it fits fine. It prints in a couple hours.
Went through a few revisions before getting it perfect. Version 3 is now uploaded with 1 and 2 deleted.
Version 2 seemed to fit fine but it came off. It may have been due to it being too hot under the hood for PETG.
Version 3 the tabs are .1mm thinner and .1mm shorter. This one was printed using PolyLite Transparent Poly Carbonate. Took it out for a 30 mile drive today and it was still attached when I got back. This one is the keeper.
Hope this helps someone else.
Small history:
11/6 - version 2 uploaded. It has thin holes instead of through holes. Cleaned up the edges a bit too. It may not be as bright, but it is more waterproof and adding the mylar is not needed.
11/19 - Version 3 uploaded. Version 1 and 2 removed.
Compatible vehicles
- 1997-2004 Chevrolet Corvette C5
Always compare with your original part before ordering. Fitment can vary by trim level and production date.
Specifications
| Part | Under Hood Light Cover |
|---|---|
| Make | Chevrolet |
| Model | Corvette |
| Year | 1997 |
| Production | 3D printed to order (FDM) |
| Design files | 1 (STL) |
| Part number | CAT-b9404347 |
Print settings
Standard FDM printing settings:
- Layer height: 0.2mm
- Infill: 70%
- Supports: As needed
How to order
This part is in our catalogue and is printed on request. Send us a request with your vehicle details and we will reply with a price and delivery time.
More Chevrolet parts
Browse all Chevrolet replacement parts or search the full 3D-printed car parts catalogue.
Design credit: original design on Thingiverse, licensed CC BY-4.0.
